Podrobný popis

Product code LHGGR&FG621-EA

CPU Dual-core 88F3720 800 MHz

CPU architecture ARM 64bit

Size of RAM 256 MB

RAM type DDR3L

Storage 16 MB, Flash

Number of 1G Ethernet ports 1

MiniPCIe slots 1

SIM slots 1 Micro SIM

LTE modem R11eL-FG621-EA

TAC 86335904

LTE Category 6 (300Mbit/s Downlink, 50Mbit/s Uplink)

MIMO DL 2x2

MIMO UL 1x1

LTE FDD bands 1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) /

28 (700 MHz)

LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)

3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)

3G bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)

RF connector type uUFL

Antenna gain 17 dBi

Dimensions 391 x 391 x 227 mm

Operating system RouterOS v7 only, License level 3

Operating temperature -40°C to +70°C

Specifications

PoE-In 802.3af/at

Supported input Voltage 12-57 V

Max current at Min voltage 0.589 A

Max current at Max voltage 0.143 A

Power adapter nominal voltage 24 V

Power adapter nominal current 0.8 A

Max power consumption without attachments 8 W

Max power consumption 8 W
